2016 Screen PT R-8600 M II SA

ALI Reference #: 106161

​Details:

• Light source: 64-channel laser diodes
• Plate size: Maximum 1,060 x 830 mm (41.7" x 32.6")
• Plate size: Minimum 450 x 370 mm (17.8" x 14.6")
• Plate thickness: 0.15 to 0.3 mm (6 to 11.8 mil)
• Productivity: 23 plates/hr (1,030 x 800 mm/40.5" x 31.4" plates) at 2,400 dpi
• Dimensions: (W x D x H) Main unit: 2,500 x 1,820 x 1,453 mm (98.5 x 71.7" x 57.3")
• Weight: Main unit: 985kg (2,167lb)
• Power requirements Main unit: Single phase 200 V to 240 V, 25 A, 4.0 kW
