Heidelberg 22 x 30.5 Cylinder Die Cutter

Heidleberg 22x30.5 Cylinder Die Cutter

ALI# 106329

The Heidelberg Cylinder Die Cutter 22" x 30.5" is a heavy-duty industrial machine used for die-cutting, creasing, perforating, and embossing paperboard and printed materials in packaging, commercial printing, and specialty finishing.

• Key Specifications Model: Heidelberg SBG / S Series Cylinder Die Cutter
• Max Sheet Size: 22.5" x 30.25" (570 x 820 mm)
• Min Sheet Size: ~11.75" x 15.75" (298 x 400 mm)
• Standard Chase Size: 22 1/16" x 28 3/8" (562 x 724 mm)
• Skeleton Chase Size: 22 1/16" x 27 3/16" (562 x 690 mm)
• Max Form Between Bearers: 20 1/4" x 27 3/16" (514 x 690 mm)
• Max Form in Std Chase: 20 1/4" x 26 3/8" (514 x 675 mm)
• Gripper Margin: 5/16" x 3/8" (10 x 9.5 mm)
• Max Speed: Up to 4,600 sheets/hour
• Punching Pressure: ~60 tons
• Net Weight: ~11,700 lbs (5,300 kg)
• Gross Weight: ~13,500 lbs (6,100 kg)
• Electrical Requirements: 240V, 40A, 3-phase
• Construction: Heavy-duty frame, precision gripper system, automatic feeder/delivery
