2019 HighCon Beam 3 Die Cutter

ALI Reference #: 106406

Details:

• Upgraded to Beam 3 in field in September 2024
• Sheet count: 3,233,225
• Type: Sheet Fed Laser Die Cutter
• Comes with: Lauda chiller & Cyclone Exhaust unit
• Max Format: 30” x 42” (760 x 1060 mm)
• Min Format: 19.7” x 27.6” (50 x 700 mm)
• Substrate
• Catronboard & Labels cutting: 8 – 36 pt.
• Cartonboard & Label creasing: 8 – 24 pt.
• Microflute: 47 pt.
• Corrugated: 78 pt.
• Max throughput: 5000 s/h
• Pile Height with pallet feeder: 3.6’
• Pile Height with pallet delivery: 3.3’
• Net cutting: 29” x 41” (745 x 1050 mm)
• Gripper margin: .47 (12 mm)
• Machine dimension: 28’ x 7’ x 7’
• Weight: 8 tons
• camera registration (so it's installed) but it didn't work for our application.
• CAD light is on the machine but whom ever buys it will need a full CAD license in order to edit/make cut and crease files
