2019 OCE i300 with 2024 Tecnau TC 1530 C2

Technology

·         Print Technology: Inkjet, drop-on-demand, piezoelectric

·         Ink: Proprietary, water-based pigment ink

·         Drop Size: Variable, Multi-level

·         Print Speed (images/min)

o   VarioPrint i300: 300 A4 images / 153 A3 images duplex

o   VarioPrint i300: 175 A4 images / 94 A3 images simplex

·         Specialty Speed (images/min)

o   VarioPrint i300: 200 A4 images / 107 A3 images duplex

o   VarioPrint i300: 168 A4 images / 94 A3 images simplex

·         Duty cycle: 1,000,000 – 10,000,000 A4 impressions/month

·         Print Resolution: 600x600 dpi with multilevel (1200 dpi perceived)

Paper

·         Paper Weight: 60–300 gsm

·         Substrates: Uncoated, inkjet treated, inkjet coated, offset uncoated, offset coated, tabs, NCR

·         Standard Configuration

·         1 Paper Input Module (PIM), Standard PIM or PIM Flex XL

1 High Capacity Stacker

·         Paper Sizes

o   203 x 203mm - 488 x 320mm

o   178 x 254mm (with optional guide)

o   203 x 203 mm - 350 x 500 mm (350 x 508 mm¹) with PIM Flex XL

·         Paper Capacity

o   4,600 sheets A4 (80 gsm) with one PIM

o   9,200 sheets A4 (80 gsm) with two PIMs

o   13,800 sheets A4 (80 gsm) with three PIMs

o   23,400 sheets A4 (80 gsm) with three PIMs and Duo Paper Trays

Standard Paper Input Module (PIM)

·         Paper Trays

o   2 x 600 sheets, 2 x 1,700 sheets (80 gsm) standard configuration

o   2 x 600 sheets, 2 x 3,300 sheets A4 (80 gsm) with Duo Paper Trays

·         Standard paper capacity

o   4,600 sheets standard configuration

o   7,800 sheets A4 with Duo Paper Trays

·         Paper Size

o   203 x 203 mm - 488 x 320 mm

o   178 x 254 mm (with optional guide)

·         Dimensions (W x D x H): 922 x 1150 x 716 mm

·         Weight: 240 kg

Paper Input Module Flex XL

·         Paper Trays: 2 x 600 sheets, 2 x 1,650 sheets (80 gsm)

·         Standard paper capacity: 4,500 sheets

·         Paper Size

o   Trays 1 and 2: 203 x 203 mm - 488 x 320 mm

o   Trays 3 and 4: 203 x 208 mm - 350 x 500 mm

·         Dimensions (W x D x H): 922 x 1150 x 716 mm

·         Weight: 240 kg

High Capacity Stacker

·         Stacks: 2 x 3,000 sheets (80gsm) per stacker

·         Dimensions (W x D x H)

o   899 x 745 x 1040 mm

o   899 x 1250 x 1040 mm with stack tray ejected

·         Weight: Empty 120 kg, full 300 kg

Integrated Camera Mounting Unit

·         Inline camera inspection

·         Dimensions (W x D x H): 305 x 745 x 1040 mm

·         Weight: 45 kg

PRISMAsync Controller

·         Network Connectivity

o   Internal: 1 x 10 Gbit Ethernet;

o   External: 2 x 1 Gbit (10/100/1000 Base-T)

o   TCP/IP (LPR /LPD, 9100 Socket), Static IP / Auto-IP (DHCP), IPv4, IPv6 (only in Document Printing mode)

·         Page description languages

o   PDF 1.7 (Extension Level 3), PDF-X (APPE 4.x RIP support), PDF/VT (Level 1), Postscript, PPML 2.2, IPDS IS/3, SRA PCL6

·         Job submission

o   lpr, Hotfolders via WebDAV, Socket (streaming), JDF/JMF, IPP 2.0, Remote PDF Driver

·         Protocols

o   SNMP v1, SNMP v3, Host Resources MIB, MIB II, Printer MIB, Job Monitoring MIB, Job Management MIB (partially), IEEE 802.1x

·         Spot Color Libraries

o   PANTONE+ Solid (Coated & Uncoated), PANTONE GOE (Coated & Uncoated), HKS (K,N), HKS (K,N) 3000+, PANTONE+ Solid 336 New (Coated & Uncoated)

Connection Requirements

·         Connection Fuse

o   230/400 VAC, 100A; 100-240 VAC, 13-20A; 100-240 VAC, 13-20A; 200-240 VAC, 13-20A; 100-240 VAC, 13-20A

·         Power Consumption – Printing: 14.9 kW

·         Power Consumption – Idle: 7.1 kW

·         Power Consumption – Sleep: 0.9 kW

·         Compressed Air: 5-12 bar, dry and oil free

·         Water: Reverse osmosis water system

Environmental

·         Temperature Optimal range 20–26°C

·         Humidity Optimal range 30–50%

·         Operating noise Printing 72 dB, Standby 61 dB

Physical data

·         Length × Width x Height: 8,800 × 2,750 x 2,400 mm

·         Weight: Approximately 8500 kg
