1982 MailCrafter 9800 6 Swing Arm Inserter

The Mailcrafters 9800 6‑Pocket Swing Arm Inserter is a high‑volume production mail inserter designed for direct mail, print finishing, and transactional mailing.

Key Specifications

• Model: 9800 / 98‑6PM (6‑station swing arm)
• Insert Stations: 6 (configurable up to 6 or more)
• Insert Size: 6″ × 9″, up to ¼″ thickness
• Envelope Size: 6½″ × 9½″ max; 3½″ × 5½″ min
• Envelope Flap Depth: Up to 2¾″ max (depending on flap construction)
• Feed System: Swing arm with 6‑pocket collating; vacuum control for document selection
• Drive System: Conjugated cam drive; rugged industrial construction
• Operator Interface: Dual control stations (start, jog, reset); safety light bar and emergency stop; some versions with color or touch‑screen panels
• Power Requirements:
• 208–240V single phase, 30A
• 220V three phase, 20A (varies by configuration)
• Motor: 1.5 HP
• Current Draw: ~30A (single phase)
• Frequency: 60 Hz
• Weight (6‑station conveyor): ~152 lbs (cabinet model adds ~900 lbs)
• B.T.U. Rating: ~2405 BTU/hr (single phase)
