1986 Rosback 220 Perf and Score

The Rosback 220 is a high-speed perforator/scorer/slitter designed for continuous, accurate production runs of hundreds to thousands of sheets.

Core Performance Features

• Speed: Up to 24,000 feet/hour
• Accuracy: 100% registration with sheet deflectors and micrometer dial for angular adjustments
• Feeding: Positive, continuous vacuum feeding (eliminates marking on sensitive stock)
• Controls: Separate vacuum and pressure controls for enhanced performance
• Ergonomics: Ergonomically located operating controls
• Durability: Heavy-duty construction, years of trouble-free operation

Standard Equipment

• 2 sets of slot perforating heads with burr rollers
• 1 set of scoring/creasing heads
• 8 perforating blades
• Drive rollers
• Full circle shaft supports (223 only)
• Tool kit and spare parts kit

Head Capacity

• Up to 5 heads

Material Handling

• Weight range: 9-lb. onionskin to 1/16" board
• Sheet size: Min. 5" x 4.6" (12.7 x 11.7 cm), Max. 20" x 23" (52 x 58 cm)
• Perf line spacing: Min. 3/4" standard; narrow margin (3/8" from edge) available
• Edge margin: Standard 3/4"
