2023 Shanklin A25i and Lantech ST700 Tunnel

Shanklin A25i

• Passage size: 10" H × 22" W × 60" L (T-71) or 12" H × 28" W × 60" L (T-81)
• Tunnel size: 68.5" H × 36" W × 92" L (T-71) or 68.5" H × 42" W × 99" L (T-81)
• Speed range: 25–150 ft/min
• Heating: Fin strip heaters, continuous 2" single-piece insulation (no hot/cold spots)
• Blower: Inverter-rated AC blower motor with balanced blower wheel
• Controls: Digital temperature control (±2°F tolerance), airflow controls
• Pairing: Designed for Shanklin Triumph 2 wrappers and other Shanklin automatic systems
• Construction: Heavy-duty, continuous insulation, optimized airflow for shrink quality

Lantech ST700

• Passage size: 51" L × 22" W × 12" H
• Tunnel size: 63" L × 22" W × 12" H
• Speed range: Up to 90 ft/min (depends on package/film)
• Heating: 3 zones, each with 3,800W heater and fan
• Airflow: Multiple fan controls (low/high) for each zone
• Controls: Single station console with ViewWindow™ for real-time process view, conveyor speed, air velocity, and temperature controls
• Conveyor: Stainless steel wire belt (glass-filled nylon optional)
• Power: 208V, 3-phase, 52A
• Weight: 980 lbs (shipping weight 1,500 lbs)
• Construction: Heavy-duty industrial components, tough composite covering
